Kingflex Colored Rubber Foam Sheet Roll

Kingflex colored rubber foam sheet roll can be customized according to customer needs in different colors.


Product Detail

Product Tags

Description

Kingflex high-quality colored rubber foam sheet looks softer, the entire hue present a sense of comfortable at the same time, it also can make the inner environment more bright,In different rubber foam colour according to the customer's requirment.

Standard Dimension

  Kingflex Dimension

Thickness

Width 1m

Width 1.2m

Width 1.5m

Inches

mm

Size(L*W)

㎡/Roll

Size(L*W)

㎡/Roll

Size(L*W)

㎡/Roll

1/4"

6

30 × 1

30

30 × 1.2

36

30 × 1.5

45

3/8"

10

20 × 1

20

20 × 1.2

24

20 × 1.5

30

1/2"

13

15 × 1

15

15 × 1.2

18

15 × 1.5

22.5

3/4"

19

10 × 1

10

10 × 1.2

12

10 × 1.5

15

1"

25

8 × 1

8

8 × 1.2

9.6

8 × 1.5

12

1  1/4"

32

 6 × 1

6

6 × 1.2

7.2

6 × 1.5

9

1  1/2"

40

5 × 1

5

5 × 1.2

6

5 × 1.5

7.5

2"

50

4 × 1

4

4 × 1.2

4.8

4 × 1.5

6

Technical Data Sheet

Kingflex Technical Data

Property

Unit

Value

Test Method

Temperature range

°C

(-50 - 110)

GB/T 17794-1999

Density range

Kg/m3

45-65Kg/m3

ASTM D1667

Water vapor permeability

Kg/(m.s.pa)

 ≤0.91×10 ﹣¹³

DIN 52 615                           BS 4370 Part 2 1973

μ

-

≥10000



Thermal Conductivity

W/(m.k)

≤0.030 (-20°C)

ASTM C 518

≤0.032 (0°C)

≤0.036 (40°C)

Fire Rating

-

Class 0 & Class 1

BS 476 Part 6 part 7

 Flame Spread and Smoke Developed Index



25/50

ASTM E 84

Oxygen Index



≥36

GB/T 2406,ISO4589

Water Absorption,%by Volume

%

20%

ASTM C 209

Dimension Stability



≤5

 ASTM C534

Fungi resistance

-

Good

ASTM 21

Ozone resistance

Good

GB/T 7762-1987

Resistance to U.V. and weather

Good

ASTM G23

Advantages of product

Kingflex colored rubber foam sheet has a low coefficient of thermal conductivity, excellent resistance to water vapor penetration ability, good fireproof performance, and different colors make the product more functional.
