Kingflex foam rubber pipe insulation

What is Elastomeric Foam Insulation?
Essentially, elastomeric foam insulation is a synthetic rubber composed of a closed-cell structure available in factory-made tubes, sheets, or rolls. The outside edge consists of a smooth surface or “skin” which serves as a built-in vapor retarder.

Due to elastomeric foam’s flexible nature, it is less susceptible to cracks, breakage, and material loss when compared to rigid insulation options such as cellular glass, polyiso and phenolic foam. Finally, it’s also fiber-free and low-VOC for chemical emissions.阿

Send email to us

Product Detail

Product Tags

Description

As a leading manufacturer nowadays we supply more than half of the region's requirements for rubber insulation products, and trade in the complete range of insulation products.

Standard Dimension

Kingflex Dimension
Thickness		Width 1m		Width 1.2m		Width 1.5m
Inches	mm	*Size(LW)**	㎡/Roll	*Size(LW)**	㎡/Roll	*Size(LW)**	㎡/Roll
1/4"	6	30 × 1	30	30 × 1.2	36	30 × 1.5	45
3/8"	10	20 × 1	20	20 × 1.2	24	20 × 1.5	30
1/2"	13	15 × 1	15	15 × 1.2	18	15 × 1.5	22.5
3/4"	19	10 × 1	10	10 × 1.2	12	10 × 1.5	15
1"	25	8 × 1	8	8 × 1.2	9.6	8 × 1.5	12
1 1/4"	32	6 × 1	6	6 × 1.2	7.2	6 × 1.5	9
1 1/2"	40	5 × 1	5	5 × 1.2	6	5 × 1.5	7.5
2"	50	4 × 1	4	4 × 1.2	4.8	4 × 1.5	6

Technical Data Sheet

Kingflex Technical Data
Property	Unit	Value	Test Method
Temperature range	°C	(-50 - 110)	GB/T 17794-1999
Density range	Kg/m3	45-65Kg/m3	ASTM D1667
Water vapor permeability	Kg/(m.s.pa)	≤0.91×10 ﹣¹³	DIN 52 615 BS 4370 Part 2 1973
μ	-	≥10000
Thermal Conductivity	W/(m.k)	≤0.030 (-20°C)	ASTM C 518
		≤0.032 (0°C)
		≤0.036 (40°C)
Fire Rating	-	Class 0 & Class 1	BS 476 Part 6 part 7
Flame Spread and Smoke Developed Index		25/50	ASTM E 84
Oxygen Index		≥36	GB/T 2406,ISO4589
Water Absorption,%by Volume	%	20%	ASTM C 209
Dimension Stability		≤5	ASTM C534
Fungi resistance	-	Good	ASTM 21
Ozone resistance		Good	GB/T 7762-1987
Resistance to U.V. and weather		Good	ASTM G23
