Rubber Insulation For Cryogenic Pipeline

Kingflex flexible ultra-low temperature adiabatic system has the inherent characteristics of impact resistance, and its cryogenic elastomer material can absorb the impact and vibration energy caused by the external machine to protect the system structure.

Send email to us

Product Detail

Product Tags

Description

The impact form any part can be widely dispersed and attenuated by elastomer material, thus avoiding the risk of cracking due to stress concentration. And also reducing the temperature change stress is that the cooling system is superior to the traditional material such as foam glass, polyurethane PIR and PUR.

Standard Dimension

Kingflex Dimension
Inches	mm	*Size(LW)**	㎡/Roll
3/4"	20	10 × 1	10
1"	25	8 × 1	8

Technical Data Sheet

Property	Base material		Standard
Property	Kingflex ULT	Kingflex LT	Test Method
Thermal Conductivity	-100°C, 0.028 -165°C, 0.021	0°C, 0.033 -50°C, 0.028	ASTM C177
Density Range	60-80Kg/m3	40-60Kg/m3	ASTM D1622
Recommend Operation Temperature	-200°C to 125°C	-50°C to 105°C
Percentage Of Close Areas	>95%	>95%	ASTM D2856
Moisture Performance Factor	NA	<1.96x10g(m.m.Pa)	ASTM E 96
Wet resistance Factor μ	NA	>10000	EN12086 EN13469
Water Vapor Permeability Coefficient	NA	0.0039g/h.m2 (25mm thickness)	ASTM E 96
PH	≥8.0	≥8.0	ASTM C871
Tensile Strength Mpa	-100°C, 0.30 -165°C, 0.25	0°C, 0.15 -50°C, 0.218	ASTM D1623
Comprssive Strength Mpa	-100°C, ≤0.3	-40°C, ≤0.16	ASTM D1621

Advantages of product

Kingflex flexible ULT insulation system does not require the use of fiber materials as expansion and expansion fillers.(this type of construction method is typical on rigid foam LNG pipes).

Our Company

Over four decades, Kingflex Insulation Company has grown from a single manufacturing plant in China to a global organization with product installation in over 50 countries. From the National Stadium in Beijing, to the high rises in New York, Singapore and Dubai, people around the world are enjoying the quality products from Kingflex.
